Foam Rubber Clamp Forklift Attachment
Foam Rubber Clamp Forklift Attachment - Image 2
Foam Rubber Clamp Forklift Attachment - Image 3
Foam Rubber Clamp Forklift Attachment - Image 4

Foam Rubber Clamp Forklift Attachment

Enquire Rental

Foam rubber clamp forklift attachments with T-shaped arms are engineered for handling sponge, foam rubber, and similar soft materials in industrial environments. The hydraulic clamping system provides precise gripping force, while integrated sideshift allows accurate load positioning. Suitable for Class II or III mounting configurations, they are compatible with a wide range of forklift models for versatile material handling.

Enquiry
Category: Tag:

Foam Rubber Clamp Forklift Attachment

The Foam Rubber Clamp is a specialised forklift attachment designed for the safe and efficient transport of non-palletized bales of foam rubber, styrofoam, and other lightweight, high-volume materials. The attachment operates hydraulically from the forklift’s system, requiring two additional hydraulic functions, and includes independent sideshift as standard for precise load positioning. Available in capacities from 500kg to 800kg with customizable opening ranges, this clamp is ideal for foam manufacturing, insulation handling, and recycling operations.

Technical Parameters

Capacity @ Load Center
Kg @ mm		 Catalog Order NO. Mounting Class Opening Range
O (mm)		 Arm Height
B (mm)		 Arm Length
A (mm)		 Frame Width
C (mm)		 Hook Spread
F (mm)		 Bar Arm Diameter
ΦD (mm)		 Weight
(kg)		 Effective Thickness
ET (mm)		 Vertical Center of Gravity
VCG (mm)		 Horizontal Center of Gravity
HCG (mm)
500@1000 HX05G-B1 ISO 3A 1270-3120 600 1825 1680 1040 Φ50 760 134 244 429
1000@500 HX10G-B2 ISO 3A 885-2310 600 1500 1100 970 Φ50 670 134 248 400
500@1000 HX05G-B2 ISO 3A 715-2565 600 3500 1680 1040 Φ50 920 134 239 833
1000@1000 HX10G-A1 ISO 2A 1450-3300 600 2525 1680 900 Φ50 880 134 241 545
1000@500 HX10G-A2 ISO 2A 650-2510 600 1825 1680 900 Φ50 800 134 245 409
1000@1000 HX10G-A3 ISO 2A 1460-3310 600 1825 1680 900 Φ50 800 134 242 397
1000@1000 HX10G-A4 ISO 2A 650-2500 600 2000 1680 900 Φ50 800 134 241 446
1000@1000 HX10G-A4-01 ISO 2A 650-2500 600 2000 1680 900 Φ50 800 134 241 446
1000@1000 HX10G-A5 ISO 2A 730-2600 600 2825 1680 900 Φ50 870 134 238 641
1000@1000 HX10G-B1 ISO 3A 730-2580 600 2825 1680 1040 Φ50 880 134 242 619
1000@1000 HX10G-B1-01 ISO 3A 730-2580 600 2825 1680 1040 Φ50 870 134 241 641
1000@1000 HX10G-B6 ISO 3A 1450-3310 600 2000 1680 1040 Φ50 830 134 242 428
1500@500 HX15G-B1 ISO 3A 750-2620 600 2525 1680 1040 Φ50 830 134 239 571
1500@500 HX15G-B2 ISO 3A 650-2500 600 1825 1680 1040 Φ50 770 134 243 413
1500@500 HX15G-B3 ISO 3A 655-2520 600 2000 1680 1040 Φ50 780 134 240 452
1500@500 HX15G-B5 ISO 3A 740-2590 600 2200 1680 1040 Φ50 800 132 241 489
1500@600 HX15G-B6 ISO 3A 470-1495 1600 1200 1010 950 Φ50 960 134 570 439
1500@500 HX15G-B7 ISO 3A 640-2490 600 2300 1680 1040 Φ50 810 134 241 516
