Product Feature

Three phase AC type motor technology
Three phase AC type motor control on travelling，lifting and steering;Good acceleration;Fast and sensitive respond on travel direction shifting;Free from maintenance motor without carbon brush having long service life and low maintenance cost;Energy regenerating during deceleration extending operation hours.

Newly designed hydraulic system

• Newly designed hydraulic system with high working efficiency;High power lifting motor;MOSTET lifting speed governing electric controller;New type low noisy gear pump，high efficiency and long life;Max. lifting speed without load 22% increased;Max. lifting speed with load 19% increased.
• Optimized intelligent design
• CAN bus technology;Parking brake on slope;Operation sequence protection;Travelling speed control;Lifting speed control;Electric controller self protection;Dead-man footswitch traction interlock.

Advanced EPS electric powered steering
EPS electric powered steering offering easy，flexible，high efficient and mute operation;Steering motor controller;Automatic centering function;Automatic limit on speed and accelerated speed when steering.

Easy operated thumb switch
To control travelling functions;Clear operating units.

Five independent braking systems
Automatic braking when accelerator lever is released;Emergency brake activated by releasing foot switch;Parking brake activated by pressing button on the panel;Automatic hold-on brake;Emergency isolator.

Displayer
High quality meter displaying important operating data;180º steering angle position display;Display of battery power and fault code;Travelling mode selection;Lifting lock indication;Hour meter;Labor hour display.

Wide view mast
Good view when loaded;Integral sideshifter;High residual load capacity at high lift height;Buffering on lifting limit;Buffering on mast moving forward and backward limit;Lift height range:2000-6500mm.

Overhead guard
Overhead guard support for improved operator protection and enhanced visibility to the load;Fence on top of the overhead guard offering driver wide view;Beveled view angle design with front ring beam meeting humanized requirements.

Comfort cab
The driver’s body is fully protected within the truck contours;Padded waist,head and arm supports;Easy reach to important operation.

The Main Parameter
