Attachment II/III Mounting Class, 1-4.5t Integral Fork Plate Push Pulls
Attachment II/III Mounting Class, 1-4.5t Integral Fork Plate Push Pulls - Image 2
Attachment II/III Mounting Class, 1-4.5t Integral Fork Plate Push Pulls - Image 3

Attachment II/III Mounting Class, 1-4.5t Integral Fork Plate Push Pulls

Enquire Rental

Push/pulls are designed for palletless handling of packaged goods. These rugged, heavy-duty attachments are ideal for high-cycle slipsheet applications that demand high productivity and low maintenance. Avertec dedicated push/pulls stand out as the highest-performing and most durable push/pulls available

Enquiry
Category: Tag: Brand:

1-4.5t Integral Fork Plate Push Pulls

Push/pulls are designed for palletless handling of packaged goods. These rugged, heavy-duty attachments are ideal for high-cycle slipsheet applications that demand high productivity and low maintenance. Avertec dedicated push/pulls stand out as the highest-performing and most durable push/pulls available.

Technical Parameters

Capacity @ Load Center (kg @ mm) Catalog Order No. Mounting Class Push Range (mm) Baffle Height × Width
C (mm) / B×A (mm)		 Minimum Truck Carriage Width (mm) Effective Thickness (mm) Horizontal Center of Gravity HCG (mm) Weight (kg) Available Forklift (t)
1600@500 TL16B-A4 II 1230 986×1014 940 305 296 615 1-2.5t
1600@500 TL16B-B2 III 1350 1050×1014 900 305 360 670 3-4.5t
1600@500 TL16B-B4 III 1230 1200×1200 950 305 300 750 3-4.5t
⚙️ All models feature integral fork plate design · Push/Pull attachment for slip sheet handling · HCG = Horizontal Center of Gravity from fork face.
